We have had a few enquiries and questions about the wires that connect the CDI to the electrical wiring loom on the XJ600 Diversion.
The pictures and info in this below should show where the different coloured wires connect to the CDI unit.
The info and pictures are from a 1998 Yamaha XJ600 S Diversion (half faired – 4BRE model) and should be the same on the XJ600 N Diversion (naked model).
Other years may be different though!
View of a 1998, 4BRE XJ600 Diversion CDI showing where the connector plug goes in
